POWER SUPPLY

• ◆ AC110、AC220V-240V 50/60Hz

• ◆ Power 30W

SPECIFICATION

◆ DMX512/1990 signal output

• ◆ 384 control channels

• ◆ There are 30 BANKS, each BANK has 8 programmable SCENES

• ◆ There are 16 adjusters to adjust the output size

• ◆ Power cycle to run the last Chase or Bank

• ◆ Built-in MIC head for sound triggering

• ◆ In the automatic trigger state, determine the automatic trigger time through the TAP SYNC key or the SPEED potentiometer

• ◆ On the MIDI interface, it can be controlled with MIDI signals at any time

• ◆ 4-digit digital display

• ◆ BLACKOUT function can be controlled manually or MIDI remotely

• ◆ CHASES programming and CHASES running functions can be controlled manually or by MIDI remote control

• ◆ Output delay function, adjust the delay time with FADE TIME potentiometer

• ◆ DMX signal output connector: XLR-D3F

• ◆ LED bulb interface

• ◆ Power input: DC9V 1000mA

SIZE

• ◆Product size: 620*230*160mm

• ◆Packing size: 620*440*4803m/6pcs (Carton)

WEIGHT

• ◆ Net weight: 5KG

• ◆ Gross weight: 26KG/6pcs(Carton)
