POWER SUPPLY

• ◆ AC100V-240V/50-60Hz

• ◆ Power 600W

OPTICS

• ◆ Lamp: Osram 371W 20R

• ◆ Color Temperature(CCT): 7000K±500K

• ◆ Average lifetime: 4000H long life platinum bubble

• ◆ Zoom angle: 3°~45°

• ◆ Lens: high precision glued optical lens

MOVEMENT

• ◆ Scanning speed: X to 2.6 seconds / 540 degrees, Y to 1.24 seconds / 270 degrees (16Bit precision scan),

• Automatic calibration positioning, fast & stable & noiseless.

COLORS/GOBOS

• ◆ Color wheel: with 14 colors + White (half-color effect, two-way rotating rainbow)

• ◆ Fixel Gobo wheel: with 13 fixed gobos + open

• ◆ Rotating Gobo wheel: with 8 rotating gobos + open, with pattern jitter and arbitrary positioning functions

EFFECTS

• ◆ Prism 1: 2 different prism elements can be inserted and rotated forward and backward.

• ◆ Prism 2: 1 prism lens and 1 atomizing lens can be inserted, and forward and reverse rotation can be realized.

• Prisms can be stacked, 16 prisms and 80 prisms can be stacked with 96 prism effects.

• ◆Focus: Electronic focusing, ultra-fine smoothing

• ◆Atomization: 0~100% soft light

• ◆Aperture: seven beam adjustment

CONTROL

• ◆ Channel: 24CH/17CH

• ◆ Standard control signal: DMX512

• ◆ Control mode: DMX mode, master-slave mode

HOUSING

• ◆ Surface: High temperature resistant plastic

• ◆ Color: Black

• ◆ IP Rating: IP20

SOFTWARE FACILITIES

• ◆ Overheating intelligent protection.

• ◆ Intelligent light bulb switch control (to extend the lamp lifetime)

HARDWARE FACILITES

◆ Ballast: Electrical

• ◆ LCD: LCD display/Touch screen

DIMMER/STROBE

• ◆ Dimmer: 0~100% linear dimming

  ◆ Strobe: 1~25 times/second, random + pulse

• ◆ Size: L350×W270×H600mm ; 720*410*810mm/2pcs(flight case)

• ◆ Net Weight: 18kg

• ◆ Gross Weight:25kg ; 59kg(2pcs in 1 flight case)
