POWER SUPPLY

• ◆ AC100V-240V/50-60Hz

• ◆ Power 350W

OPTICS

• ◆ Lamp: MSD 295W

• ◆ Color Temperature(CCT): 8500K

• ◆ Average lifetime: 2,200 hour

• ◆ Beam angle: 0-4 degree

MOVEMENT

• ◆ Scanning speed: Pan scan：540°(16bit) Electric correction；Tilt scan：270° (16bit) Electric correction

COLORS/GOBOS

• ◆ Color wheel: 14 colors + white, halftone effect adjustment

• ◆ Gobo wheel: 14 gobos + white

EFFECTS

• ◆ Prisms: 8-facet prism


• ◆ Frost: Soft light effect, easy to achieve the effect of soft and fantasy pattern

CONTROL

• ◆ Channel: 16CH(without ring)/18CH(with ring)

• ◆ Standard control signal: DMX512

• ◆ Control mode: international standard DMX512, automatic and master/ slave mode

HOUSING

• ◆ Surface: High temperature resistant plastic

• ◆ Color: Black

• ◆ IP Rating: IP20

• ◆ Size: 580*380*420mm/carton

• ◆ Net Weight: 16kg ; GW: 17kg

•
