POWER SUPPLY

• ◆ AC100V-240V/50-60Hz

• ◆ Power 600W

OPTICS

• ◆ Lamp: Osram 371W

• ◆ Average lifetime: 1,500 hour (pack lamp & reflection cup to lengthen lifetime)

• ◆ Beam angle: 2 degree

• ◆ Lens: high precision glued optical lens

MOVEMENT

• ◆ Scanning range: X axis 540 degrees, Y axis 270 degrees,Support XY inversion, adjustable scanning speed

COLORS/GOBOS

• ◆ Color wheel1: with 14 colors + blank Can rotate in both directions, speed can be adjusted to achieve half-color effect

• ◆ Color wheel2: 1 6-color rainbow color plate

• ◆ Gobo wheel: with 13 fixed pattern pieces + blank,Can rotate in both directions, speed can be adjusted, and pattern dithering is supported

EFFECTS

• ◆Prisms: One 8 prism, one 16 prism, can rotate in both directions, speed can be adjusted,Achievable overlay effect

• ◆Focus: 0-100% Linear focus

• ◆Soft effect: Adjustable soft spot angle

• ◆Aperture: seven beam adjustment

CONTROL

• ◆ Channel: 16/20CHs

• ◆ Standard control signal: DMX512

• ◆ Control mode: international standard DMX512, automatic and master/ slave mode

HOUSING

• ◆ Surface:High-strength engineering flame-retardant plastic case

• ◆ Color: black

• ◆ IP Rating: IP65

SOFTWARE FACILITIES

• ◆ Overheating intelligent protection.

• ◆ Intelligent light bulb switch control (to extend the lamp lifetime)

HARDWARE FACILITES

◆ Ballast: Electrical

• ◆ LCD: LCD display/Touch screen

• ◆ Other functions: 6-layer coated high-precision glued optical lens, XY positioning automatic error correction function;The display can query the lamps and lanterns, the use time of the lamp is easy to maintain; the fan automatically adjusts the speed;Automatically reduce the light source power by 50% when the machine is closed

DIMMER/STROBE

• ◆ Dimmer: 0-100% linear adjustment

  ◆ Strobe: 1-25HZ strobe, speed adjustable

• ◆ Size:450*400*700mm(LWH)

• ◆ Net Weight: 28.7kg
