POWER SUPPLY

• ◆ AC100V-240V/50-60Hz

• ◆ Power 250W

OPTICS

• ◆ Led: 150W High Output White LED

• ◆ Average lifetime: 50,000 hour

• ◆ Beam angle: 6 degrees

• ◆ Lumen:  3450LUX@5M at White light

MOVEMENT

• ◆ Scanning speed: X 540 degrees, Y  270 degrees

COLORS/GOBOS

• ◆ Color wheel: 7 colors +white, rotation with variable direction and speed

• ◆ Gobo wheel 1:8 gobos +white, wheel rotation and shake(Static)

• ◆ Gobo wheel 2: 6 gobos +white, wheel rotation and shake(Rotation)

EFFECTS

• ◆Prisms: 8  prisms. Variable speed rotation in both directions

CONTROL

• ◆ Channel: 16/14/12/10 DMX Channels USITT DMX-512

• ◆ Standard control signal: DMX512

• ◆ Control mode: international standard DMX512, automatic and master/ slave mode

HOUSING

• ◆ Surface: High temperature resistant plastic

• ◆ Color: black

• ◆ IP Rating: IP20

SOFTWARE FACILITIES

• ◆ Temperature protect function, when the internal
      Temperature is up to 40° and then the fans begin to work,
      when the internal temperature is up to 70°and the brightness reduce half.

HARDWARE FACILITES

◆ Ballast: Electrical

• ◆ Motors: Three-phase motor running speed.Efficient low noise fan cooling system

• ◆ LCD: LCD display

DIMMER/STROBE

• ◆ Dimmer: 0-100% linear adjustment

  ◆ Strobe: High speed strobe effect with 1-25 flashers per second

• ◆ Size: 270*270*470mm (LWH) ; 305*305*500mm/carton

• ◆ Net Weight: 11kg

• ◆ Gross Weight: 14kg
