Beam moving head light 380W 20R

LED Beam Moving Head Light 150W

Model
LD-2205D-1
Size
305*305*500mm (LWH)
Weight
14kg
Beam angle
6 degrees
Lamp
LD-2205D-1
Color Temperature(CCT)
2500-8500K
Average lifetime
50,000hours
Certificates
CE , RoHS, REACH, ISO 9001
Payment Team
Bank Transfer/ Credit card/L/C/Western Union
Delivery Time
3-5 working days after received deposit
Package
Export carton or road case
Price
Get Latest Price
Get the latest price
Quantity Needed:
Pieces
E-mail:

❈ Product Parameters ❈


MODEL

  • ◆ LD-2205D-1

POWER SUPPLY

  • ◆ AC100V-240V/50-60Hz

  • ◆ Power 250W

OPTICS

  • ◆ Led: 150W High Output White LED

  • ◆ Average lifetime: 50,000 hour

  • ◆ Beam angle: 6 degrees

  • ◆ Lumen:  [email protected] at White light

MOVEMENT

  • ◆ Scanning speed: X 540 degrees, Y  270 degrees

COLORS/GOBOS

  • ◆ Color wheel: 7 colors +white, rotation with variable direction and speed

  • ◆ Gobo wheel 1:8 gobos +white, wheel rotation and shake(Static)

  • ◆ Gobo wheel 2: 6 gobos +white, wheel rotation and shake(Rotation)

EFFECTS

  • ◆Prisms: 8  prisms. Variable speed rotation in both directions

CONTROL

  • ◆ Channel: 16/14/12/10 DMX Channels USITT DMX-512

  • ◆ Standard control signal: DMX512

  • ◆ Control mode: international standard DMX512, automatic and master/ slave mode

HOUSING

  • ◆ Surface: High temperature resistant plastic

  • ◆ Color: black

  • ◆ IP Rating: IP20

SOFTWARE FACILITIES

  • ◆ Temperature protect function, when the internal
        Temperature is up to 40° and then the fans begin to work,
        when the internal temperature is up to 70°and the brightness reduce half.

HARDWARE FACILITES

◆ Ballast: Electrical

  • ◆ Motors: Three-phase motor running speed.Efficient low noise fan cooling system

  • ◆ LCD: LCD display

DIMMER/STROBE

  • ◆ Dimmer: 0-100% linear adjustment

    ◆ Strobe: High speed strobe effect with 1-25 flashers per second

SIZE
  • ◆ Size: 270*270*470mm (LWH) ; 305*305*500mm/carton

WEIGHT
  • ◆ Net Weight: 11kg

  • ◆ Gross Weight: 14kg





❈  PRODUCT EFFECT ❈

LED Beam Moving Head Light 150W(图1)

LED Beam Moving Head Light 150W(图2)

LED Beam Moving Head Light 150W(图3)

LED Beam Moving Head Light 150W(图4)
