POWER SUPPLY

• ◆ AC100V-240V/50-60Hz

• ◆ Power 180W

OPTICS

• ◆ LED: 1*90W/120W high brightness white LED

• ◆ Average lifetime: 50,000 hours

• ◆ Beam angle: 4 degree

MOVEMENT

• ◆ Scanning speed: 16 bit smooth and precise resolution for PAN/TILT movement

• ◆ Pan: 540 degree + fine Tilt: 270 degree + fin

• ◆ Color wheel:1 color wheel with 5 colors plus open

• ◆ Static Gobo Wheel: 1 static gobo wheel with 7 fixed gobos plus ope

EFFECTS

• ◆ Prism: 1 rotatable 5-facet prism with speed adjustable and varialble direction

• ◆ Dimmer: 0-100%  linear dimmer

• ◆ Strobe: 1-18 times/sec high speed electronic strobe


• ◆ Frost: Soft light effect, easy to achieve the effect of soft and fantasy pattern

CONTROL

• ◆ Channel: 13CHs

• ◆ Standard control signal: DMX512

• ◆ Control mode: international standard DMX512, automatic master/ slave mode

• ◆ Screen: LCD screen


HOUSING

• ◆ Surface: High temperature resistant plastic

• ◆ Color: black

• ◆ IP Rating: IP33

• ◆ Size: 48*38*41cm/pc

• ◆ Size: 75*73*42cm/2pcs (flight case)

• ◆ Net Weight: 12.5kg

• ◆ Gross Weight: 15kg/p

• ◆ Gross Weight: 50kg/2pcs(flight case)
